LED Modules
Are you ready to brighten up the UK using our LED Modules?
Plenty of options, plenty of colours!
SG1 LED Module
£0.50
- Our 12v, SG1 modules are 0.3w and 27lm each
Sized at 18 x 8 x 3mm and available in two colours:
Pure White - 6500K
Warm White - 3000K
- An Ultra Slim LED module, it's tiny, bright and wonderful.
- Perfect for halo illumination on flat cut letters, shallow built up letters or awkward shapes where space is at a premium.
- 64mm centre to centre at full stretch.
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide
-
Colours - Pure White (6500K), Warm White (3000K)
Modules per chain - 20
Beam Angle - 120 degrees
Lumens - 27lm
Wattage - 0.3w
Voltage - 12v
Dims (LxWxH) - 18mm x 8mm x 3mm
Lifespan - 13,000hrs
IP Rating - IP65
SG2 LED Module
£0.50
-
Our 12v, SG2 LED modules are 0.25w and up to 15lm each
Sized at 26 x 7 x 4mm and available in 3 colours:
Pure White: 6500K/15lm
Blue: 460-480nm/71lm
Red: 620-640nm/6lm
- They're narrow, bright and unique. It will fit into very narrow stroke widths without any problems.
- Perfect for face & halo illumination on narrow built up letters or awkward shapes where space is at a premium.
- 80mm centre to centre at full stretch.
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide
-
Colours - Pure White (6500K), Blue (460-480nm), Red (620-640nm)
Modules per chain - 20
Beam Angle - 140 degrees
Lumens - W 15lm, B 7lm, R 6lm
Wattage - 0.25w
Voltage - 12v
Dims (LxWxH) - 26mm x 7mm x 4mm
Lifespan - 20,000hrs
IP Rating - IP65
SGMINI LED Module
£0.50
- Our 12v, SGMINI modules are 0.24w and 28lm each
Sized at 9 x 6 x 4mm available in Pure White, 6500K
- This tiniest of tiny LEDs is a marvel to behold. Small, robust and waterproof. What more could you want? It will fit into the tightest of spaces without compromising on quality and even lighting.
- Perfect for face and halo illumination on shallow built up letters or awkward shapes where space is at a premium.
- 27mm centre to centre at full stretch
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide
-
Colour - Pure White (6500K)
Modules per chain - 20
Beam Angle - 120 degrees
Lumens - 28lm
Wattage - 0.25w
Voltage - 12v
Dims (LxWxH) - 9mm x 5.9mm x 4mm
Lifespan - 50,000hrs
IP Rating - IP65
SG3 LED Module
£0.56
- Our 12v, SG3 modules are 0.3w and up to 25lm each
Sized at 39 x 12 x 4mm and available in 6 colours:
Pure White - 6500K/25lm
Warm White - 3000K/25lm
Blue - 460-480nm/7lm
Red - 620-640nm/5lm
Green - 510-540nm/15lm
Yellow - 586-594nm/6lm
- Our crazily versatile SG3 modules are the workhorse of our range.
- Perfect for face & halo illumination built up letters, lightboxes, backlighting and decoration where consistancy and reliability is key.
- 90mm centre to centre at full stretch
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide -
Colours - Pure White (6500K), Warm White (3000k), Blue (460-480nm), Red (620-640nm), Green (510-540nm), Yellow (586-594nm)
Modules per chain - 20
Beam Angle - 140 degrees
Lumens - W 25lm, B 7lm, R 5lm, G 15lm, Y 6lm
Wattage - 0.3w
Voltage - 12v
Dims (LxWxH) - 39mm x 12mm x 4mm
Lifespan - 20,000hrs
IP Rating - IP65
HB2 LED Module
£1.00
- Our 12v, HB2 modules are 0.48w and 44lm each.
Sized at 47 x 15 x 4mm and available in 2 colours:
Pure White - 6500K
Warm White - 3000K
-If you want a combination of very bright, even illumination & efficiency, the HB2 is the module for you.
- Perfect for built up letters/shapes & lightboxes
- 130mm center to centre at full stretch
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide - Colours - Pure White 6500K, Warm White 3000K
Modules per chain - 20
Beam Angle - 150 degrees
Lumens - 44lm
Wattage - 0.48w
Voltage - 12v
Dims (LxWxH) - 47mm x 15mm x 4mm
Lifespan - 50,000hrs
IP Rating - IP65
RGB2 LED Module
£1.10
- Our 12v, RGB2 modules are 0.48w and 21lm each
Sized at 47 x 15 x 4mm
- 2 diode RGB LED modules are sealed within resin in plastic cases. They come with VHB tape applied to the backs for easy installation.
- Perfect for built up letters, signcase/fretcut Lightboxes & projection signs.
- 130mm centre to centre at full stretch
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide -
Colour - RGB
Modules per chain - 20
Beam Angle - 140 degrees
Lumens - 21lm
Wattage - 0.48w
Voltage - 12v
Dims (LxWxH) - 47mm x 15mm x 4mm
Lifespan - 50,000hrs
IP Rating - IP65
CB1 LED Module
£1.30
-
Our 12v, CB1 modules are 1.4w and 100lm each
Sized at 36 x 18 x 8mm and available in Pure White, 6500K
-If you want are looking for a very bright, high quality module, which can be used in a range of places, then you've found it!
- Perfect for signcase or fretcut lightboxes, large built up letters and projection signs.
- 120mm centre to centre at full stretch.
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide
*These need to be fit to a heat conductive backing such as aluminium or steel to help with heat dissipation
-
Colour - Pure White 6500K
Modules per chain - 20
Beam Angle - 160 degrees
Lumens - 100lm
Wattage - 1.4w
Voltage - 12v
Dims (LxWxH) - 36mm x 18mm x 8mm
Lifespan - 13,000hrs
IP Rating - IP65
LB200 LED Module - 3pk
£7.00
- Our 12v, LB200 modules are 2.8w/200lm each - 8.4w/600lm per set of 3
Sized at: 41 x 31 x 11mm and available in Pure White, 6500K
- Sold in packs of 3, our LB200 is THE module for backlighting lightboxes. You can't buy brighter!!
- Using the highest quality CREE Leds, you get uniformity in both colour and brightness, unparalleled with any other brand.
- Perfect for signcase/fretcut lightboxes & projection signs.
- 240mm centre to centre at full stretch
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide
*The modules must be fit in multiples of 3 and will not work if wired individually.
*These need to be fit to a heat conductive backing such as aluminium or steel to help with heat dissipation -
Colour - Pure White 6500K
Modules per chain - 18
Beam Angle - 160 degrees
Lumens - 200lm
Wattage - 2.8w
Voltage - 12v
Dims (LxWxH) - 48mm x 31mm x 11mm
Lifespan - 30,000hrs
IP Rating - IP65
EL200 LED Module - 3pk
£7.50
- Our 12v, EL200 modules are 2.8w/200lm each - 8.4w/600lm per set of 3
Sized at 48 x 31 x 11 and available in Pure White, 6500K
- This is the mother of all LED modules used for lightboxes. Using the highest quality Cree led diodes, the output is twice as bright as it's closest rival.
- Unlike other modules these are designed to be fastened to the inside return of a lightbox so the LEDs point up and down.
- They can be fastened to aluminium angle within a lightbox if you are only trying to light up a smaller section of the sign.
- Perfect for single/double sided Lightboxes & projection signs.
- 200mm centre to centre at full stretch.
Download our LED Facts & Spacings Guide
Download our LED Wiring Guide
*The modules must be fit in multiples of 3 and will not work if wired individually.
*These need to be fit to a heat conductive backing such as aluminium or steel to help with heat dissipation -
Colour - Pure White 6500K
Modules per chain - 18
Beam Angle - 38 degrees
Lumens - 200lm
Wattage - 2.8w
Voltage - 12v
Dims (LxWxH) - 48mm x 31mm x 11mm
Lifespan - 30,000hrs
IP Rating - IP65
Flexible LED Module Panel
£28.00
-
Our 12v, flexible LED module panel is made up of 105no individual modules of 0.3w/33lm each: 32w/3465 per panel.
Overall panel size is 504 x 235 x 7mm and it is available in Pure White, 6000K
- It can be cut into unusual shapes, using the red lines, for easy fitting.
- A minimum return depth of 50mm will give even illumination.
- Easy to fit either by soldering or using the 8no single connectors supplied, each module has 4no connecting points.
- Superb flexibility means it can be applied to curved surfaces and can be rolled into a tube.
-
Colour - Pure White (6000K)Rated - IP20
Wattage - 0.3w per module/32w per sheetLumens - 33lm per module/3465lm per panelVoltage - 12v
Beam angle: 160*Sheet Size - 504mm x 235mm x 7mmMin. Return Depth: 50mm - Datasheet Download
