6x12 Dome LED Neon Flex FEATURES
• Ideal for internal and external lighting applications
• SMD3528 LED modules >55Lm/w
• 6 colours*, and 2 whites, available as standard
• 12v / 120 LEDs/m / 8-10w/m / <360LM/m
• Size: 6x12mm
• Beam angle: 160°
• Bending diameter: 30mm
• Dimmable / Horizontal Bend / 10 & 25mm cut points
• 2 year Warranty
Use these LEDs with our 12v Power Supplies & Dimmers
Note: Colours require an extra day lead time.
**Pink 10mm cut points Temporarily Out of Stock** New stock due in w/c 8/3/21
Our 6x12 Dome Mini LED Neon Flex is super flexible and ideal for the trendy neon look signs. It creates brilliant lighting around anything. Ideal for visual merchandisers and designers alike, everything about this strip makes it great for window displays, POS, shelving and bespoke lighting and perfect for lettering.
It's IP67 rating makes it perfect for internal or external applications.
All colours are available by the metre and in 50m** reels:
Pink, Green, Blue, Red, Yellow, Orange and Pure & Warm White
You will need the following tio make the LED Neon Flex work:
- Neon Flex*
- 2 x Neon Flex End Caps - Coming Soon!
- 1 x 12v power supply
Purchase more than 1m length and it will be supplied in one piece up 50m
*When this item is sold by the metre, there is a chance it will be from a part roll that won't have any wire attached.
**50m reels may be on Special Order with a lead time of 10-15 days. Please get in touch for more information.
The 6x12 Dome Mini Led Neon Flex is too small to have connecting pins so the cable for this product will need to be soldered on.
End Caps are available for this profile - Coming Soon!
- 6mm x 12mm with a domed face
- Available in 8 colours: Pink, Green, Blue, Red, Yellow, Orange and Pure & Warm White
- Horizontal Bending
- 150w 12v PSU will power 14m of static flex @ 10w p/m
We Will Beat Any Like For Like Price!
Seen it cheaper? Let us know
The 6x12 Dome Mini Led Neon Flex, 12v, can be powered from just one end up to 5m and 8m with power to both ends. It has a horizontal bend.
Download the Datasheet
LED Neon Flex Fitting Guide
*Whilst we endeavour to never mix batches on the same order, LEDs bought at different times, may have slightly different colours.
Cut Points and Colours
• 10mm - Red
• 25mm - Pink
• 25mm - Blue
• 25mm - Green
• 25mm - Orange
• 25mm - Yellow/Amber
NOTE: All jacket colours are White, as standard. This means when they are not illuminated they look white.
• LED: SMD2835
• Size: 6x12mm
• Voltage: 12V DC
• Wattage: 8±2W per metre (at full power)
• Beam Angle: 160°
• Lumens/w: >30
• Lumens/m- >360
• Bend: Horizontal / 30° diameter
• Fixing: Plastic Mounting Clips, 2 p/m
• Lifespan: 30,000 hours
• Warranty: up to 12 months
• Rating: IP67 with appropriately rated accessories
