Lighting & Cable Connectors
Professional Lighting Connectors
Quick and affordable lighting connectors as used by the professionals. Reusable splice, gel, and plug-in lighting cables for connecting cables and electrical circuits. Our range of cable connectors includes a wide variety of styles & connection types, for any and all applications.
5m Double Wire Adaptor - 3A
£7.50
- 5mm Twin wire extension lead
2.1mm DC socket to 2.1mm DC plug
Supplied with 2x 3-port lever connectors - Black PVC Insulation Sheath
Current Rating: 3A
Suitable for 12v or 24v
Perfect for marquee 'LOVE style' letters
Extension for 1.5mm cable to 'plug' style PSU - Datasheet Download
2, 3 & 5 Port Lever Clamps - 10pk
£4.00
- Lever Cage Clamp Terminal Block (0.08-4.0mm, Pack of 10)
Available as 2-port, 3-port & 5-port
Cage clamp inside the connector block
Integrated orange levers for easy use - Each size is packed in 10
Conductor Sizes: 0.08mm - 2.5mm solid core & stiff stranded core - 0.08mm - 4.0mm flex
Sizes:
- 2 port: 20.5Lx14.5Wx12.4Hmm
- 3 port: 20.5Lx14.5Wx17Hmm
- 5 port: 20.5Lx14.5Wx26.6Hmm
Strip length: 9-10mm
Single pole commoning terminal
Colour: Grey/Orange
Current rating 32A
Voltage rating 0-400v/4kv - Datasheet Download
Dexgreen 8A IDC Connector - 50, 100 or 500 pks
£4.00
- Dependable electrical connection for most signage applications
Ideal for the LED Modules
Metal components are resistant to or protected against general corrosion and various forms of localized corrosion, including stress corrosion cracking and pitting.
Available in 50's, 100's or 500's - Current Rating: 8A
Will accommodate conductors from 0.4mm through to 0.9mm
Gel filled for moisture resistance
Will not produce galvanic corrosion effects, in wet or humid conditions
Butt splice connection - Datasheet Download
DC Power In-Line Socket Screw Termination - 2.1mm - 1A
£1.30
- Standard DC Power Female Adaptor
Designed to accept 2.1mm jack plugs
This adaptor allows you to connect a barrel jack connector to bare wires - no need to solder.
One end has screw terminals and the other has a 5.5x2.1mm, center-positive female barrel jack.
Fit directly onto the Plug-in Style PSUs available making a quick and easy connection. - Suitable for 12v & 24v
Current rating: 2A
Straight type 2.1mm connector size
Brass contact material
Dimensions: 38 x 14 x 13mm
Integral cable strain relief 20-1066
Scotchlok UR2 Connectors - 50 or 100pk
£16.50
- 3M Scotchlok's UR2 unique 'U' contact provides a dependable electrical connection.
Scotchlok's insulation displacement connectors (IDCs) are easy to use and save time to install. To install one, just squeeze - no stripping or twisting.
Gel filled for moisture resistance.
Designed to accept 2 or 3 solid, copper conductors -
Wiring without stripping For vibration proof and permanent connections
Composition: gel filled
Cable cross-section: 0.4-0.9mm (AWG 26-19)
External diameter: 2.08mm
Specification: Splitter, red cap
0.082-in O.D. insulation
Accommodates 26 to 19 AWG conductor sizes
Durable polypropylene construction
- Datasheet Download
Splice Red Connector, 100pk
£10.00
- Direct tapping into existing insulated copper wire
- Wire Size: 0.8 to 2mm
Size: 22Lx13.2Hx20Wmm
Brass contact material, tin contact plating
Internal Diameter: 3.7mm
Voltage Rating: 600V
AWG: 22 - 18
Suitable for insertion of additional cables
Wire Connector - Single Clasp with 150mm wire - 8A
£1.10
- For joining 8mm wide ECO LED strip without soldering
- Clasp at one end of a 150mm wire
Rated 8A
Sold singularly
Scotchlok UB2A Connectors - 100pk
£30.00
- 3M's Scotchlok UB2A IDC Connector makes a moisture resistant tap splice connection between three solid-copper conductors of air-core or filled cable.
Pre-crimp feature equates to a time saver for the craft person.
Sealant is a mineral oil-based grease -
Wiring without stripping For vibration proof and permanent connections
Composition: gel filled to protect against corrosion and to seal out moisture
Cable cross-section: 0.4-0.9mm (AWG 19-26)
External diameter: 2.08mm
Specification: Splitter, blue cap
0.082-in O.D. insulation
Durable polypropylene construction
- Datasheet Download
DC Power In-Line Screw Termination Plug, 2.1, 2A
£1.20
- Standard DC Power Male Adaptor
This adaptor allows you to connect a barrel jack connector to bare wires - no need to solder.
One end has screw terminals and the other has a 5.5 x 2.1mm, center-positive male barrel jack. - Suitable for 12v & 24v
Current rating: 2A
Straight type 2.1mm connector size
Brass contact material
Dimensions: 38 x 14 x 13mm
Integral cable strain relief 20-1066
Wire Connector - Double Clasp with 150mm wire - 8A
£1.40
- For joining 8mm wide ECO LED strip without soldering
- Clasp at both ends of a 150mm wire
Rated 8A
Sold singularly
DC Power In-Line Solder Termination Socket, 2.1mm, 2A
£1.60
- Standard DC Power In-Line Socket with Solder Terminal
Designed to accept 2.1mm power plugs - perfect for the Plug-In Style PSUs - Suitable for 12v
Current rating: 2A
Straight type 2.1mm connector size
Bronze contact material
Integral Cable Strain Relief - Datasheet Download
Crimping Tool for Gel Connectors
£18.00
-
Stepped jaws with long nose
For use on conductors less than 19 gauge (0.9mm)
Specifically designed to crimp the gel connectors Dexgreen and 3M UR2A & UB2
Can also be used with the 3M UR2A-D dry connector
DC Power Socket - 2.1mm - 1A
£1.44 £1.60
- Standard DC Power Socket designed for a flush mounting to a panel using a single hole of 8.5mm
Designed to accept 2.1mm power plugs
Solder Terminal
Supplied with washer and hexagonal fixing nut - Suitable for 12v
Current rating: 1A
Straight type 2.1mm connector size
Solder lug termination - Datasheet Download
T2 Splice Connector, 50pk
£25.00
-
Our T2 Splice Connector couldn't be easier to use!
No need to strip the wires and no soldering with this innovative lock flap style connector.
Just insert wires and squeeze to make fast, secure connections.Ideal for use with low voltage lighting, audio, video etc., they are splash and dust proof.
- Wire Size: 18-22AWG
Size: 29Lx9Hx17Wmm
Brass contact material, tin contact plating, flame retardant plastic housing.
Voltage Rating: 12/24vdc 300vac
Current: 0-10A
Operating Temp.: -30~+85*C
Suitable for insertion of additional cables
Wire Clasp - 8A
£0.55
- For joining 8mm wide ECO LED strip without soldering
- Rated 8A
Sold singularly
DC Power In-Line Plug - 2.1mm - 1A
£0.50
- Standard DC Power In-Line Plug
Solder terminal with anti kink housing - Suitable for 12v
Connector size: 2.1mm
Brass contact material
Black colour
Standard plug with 10mm shaft - Datasheet Download
LED Connector & Cable Kit - Starter
£35.70
To help those of you who are keen to use LED but aren't quite sure of the best way to...
View full product details
5m Single Wire Adaptor - 3A
£6.00
- 5mm Twin wire extension lead
2.1mm DC socket to bare ends
Supplied with 2 x 3-port lever connectors - Black PVC Insulation Sheath
Current Rating: 3A
Suitable for 12v or 24v
Perfect for marquee 'LOVE' style letters
Extension for 1.5mm cable to 'plug' style PSU
Wago Junction Boxes - Grey, Black, White & Red
£2.80
- Available in Grey, Black, White & Red
The Wagobox is a fantastic multipurpose electrical enclosure that has been designed to house the acclaimed Wago 222 connector series.
It is the first of its type and redefines the standard for general domestic and commercial junction boxes. With all the connections being made in free space and the cables and connectors simply slotted into place, its unique patented design makes the job of assembling electrical junction boxes simpler, quicker and safer.
The Wagobox also has a fast fit slide action mounting point so the box can be fixed to a surface after the connectors have been fitted into the box by using the Wagobox mounting button - Sold seperately. - Current Rating: Max 40A
Voltage Rating: 400v/4kv
Suitable for:
- 3 x 6.0mm Twin & Earth
- 4 x 4.0mm Twin & Earth
- 6 x 1.0, 1.5 or 2.5mm Twin & Earth
- 6 x 1.0 or 1.5mm 3-core & Earth.
- 6 x Flex up to 8mm OD
Grip ability from 3mm to 8mm - Datasheet Download
Click Flow Connector CT102C
£3.00
-
Designed initially for lighting circuits to enable isolation of transformers, control gear etc, whilst conducting a 1000V insulation resistance test.
- Versatile easy-connection system for fixed wiring applications.
- 3-pole plug-in connector with loop terminal.
- Cable grips for where the installation limits the fixing of the connector.
- Fast, simple and safe design.
- Large terminal with easy access
-
Voltage: 250V
Rated 250V, 20A
Male: Max. 2.50mm 3 core cable
Female: Max. 3 x 2.50mm twin and earth (with additional loop terminal)
Dimensions (HxWxD): 23 x 45 x 105mm
T1 Splice Connector, 50pk
£18.00
-
Our T1 Splice Connector couldn't be easier to use!
No need to strip the wires and no soldering with this innovative lock flap style connector.
Just insert wires and squeeze to make fast, secure connections.Ideal for use with low voltage lighting, audio, video etc., they are splash and dust proof.
- Wire Size: 18-22AWG
Size: 25Lx9Hx12Wmm
Brass contact material, tin contact plating, flame retardant plastic housing.
Voltage Rating: 12/24vdc 300vac
Current: 0-10A
Operating Temp.: -30~+85*C
Scotchlok UB2A-D Connectors - 100pk
£30.00
- 3M Scotchlok UB2A-D is a dependable electrical dry connection
This single IDC Bridge Tap Connector is designed to accommodate 2 conductors.
It is ideal for use on PIC, pulp and paper cables.
Proper positioning of the connector on the conductor and pre-crimping prevents the conductor from slipping out of the connector before the crimp is completed.
The connector is designed to provide direct tapping into existing solid copper conductors without interrupting service. -
Wiring without stripping For vibration proof and permanent connections
Composition: dry
Cable cross-section: 0.4-0.9mm (AWG 19-26)
External diameter: 2.08mm
Specification: Splitter, white cap
Durable polypropylene construction
- Datasheet Download
Outdoor Electrical Capsule
£13.00
- Multipurpose IP68 adaptable junction box
Ideal for a wide range of outdoor applications, whether surface mounted or buried into the ground. - Designed for use with wago pushwire and cage clamp connector blocks
Full instructions enclosed with the unit
Surface mounting bracket sold seperately
LED Connector & Cable Kit - Expert
£152.60
Our LED Connector & Cable EXPERT Kit is perfect for those of you that have LED experience and appreciate the...
View full product details
