DOT12 LED Module 12v

£0.60

• Description
• Details at a glance
• Downloads

• DOT12 LED Modules 12v

  Our 12v DOT12 LED Module is designed to add decorative finishes to almost any surface.  The DOT12 pushes through from the back of the material and has a beam angle of only 90° to give that 'spotty' effect you want from them.

  Available in Cool White (9000K)

  Click here to see our DOT12RGB module

  Please download our specification PDF, in the tabs above, for more information.

  As with all our LED modules, it is completely encapsulated for outdoor use.

  Please Note:
  *Whilst we endeavor to never mix batches on the same order, LEDs bought at different times, may burn at different colours.

  Extra Info

  To fit the DOT12 you need to drill a 10mm hole in your material, a max of 70mm apart, and push through from the back. The material thickness must be a maximum 3mm thick.

  Need a power supply? See our 5v Power Supplies perfect for the DOT12RGB.

  The 'Qualität' brand of LED modules are a very good quality, mid-high range LED. They offer the specification you would expect from more expensive modules, whilst keeping a very low price.

  We Will Beat Any Like For Like Price!
  Seen it cheaper? Let us know



• Details at a Glance

  • 29mm x 14mm
  • 12V DC
  • 0.3W per module (at full power / White)
  • 50 dots per string
  • 70mm max led spacing
  • 7 lumens (at full power / White)
  • 90° Beam Angle
  • 2 Year Warranty
  • 30,000hrs expected lifespan
  • IP66
