Hole Support for Micro Connector System

£1.15

• Description

•  Two part socket and adapter designed specially for threading Micro Connector System leads with bare ends giving a safe, professional finish to your project.


Negative stickers

£5.00

Each 160mm x 283mm sheet has 80no printed premium vinyl stickers, 10mm x 30mm, to attach to negative cables for easy identification

Positive stickers

£5.00

Each 160mm x 283mm sheet has 80no printed premium vinyl stickers, 10mm x 30mm, to attach to positive cables for easy identification

PE6 LED Module

£1.90

• Description
• Details at a glance
• Data & Spacings Guide

• PE6 LED Modules

  Our 'Perfekt6' LED Module is designed for face of large lightboxes that need to pack a punch. The PE6 module has a beam angle of 170° so works very well with large lightboxes and flex faces from a return depth of 200mm.
  Please download our specification PDF, in the tabs above, for more information.

  Available in 1 colour*: Pure White (6600/7300K)

  As with all our LED modules, it is completely encapsulated for outdoor use and comes with suitable VHB tape already applied. It includes an integrated heat sink to reduce light degradation and colour deviation.

  Please Note:
  *Whilst we endeavor to never mix batches on the same order, LEDs bought at different times, may burn at different colours.

  Extra Info

  Need a power supply? See our 12v Power Supplies

  The 'Perfekt' brand of LED modules are a high end quality LED. They offer the specification you would expect from the best, with exceptional value for money.

  We Will Beat Any Like For Like Price!
  Seen it cheaper? Let us know



• Details at a Glance

  • Available in 1 colour: Pure White (6500K)
  • 74mm x 48mm x 7mm
  • 12V DC
  • 3W per module (at full power / White)
  • 285 lumens (at full power / White)
  • Pre-mounted adhesive tape to rear
  • 170° Beam Angle
  • 3 Year Warranty
  • 50,000hrs expected lifespan
  • IP67

• Spacings Info

  • 250mm - Full Stretch Centre to centre spacing
  • 50mm - Minimum return depth for even illumination


  • Row & LED Spacings Guide
    50mm Returns <  = 100mm spacings
    100mm Returns <  = 110mm spacings
    150mm Returns <  = 150mm spacings
    200mm Returns <  = 250mm spacings


  Click here to download our LED Modules Data Guide
  Click here to download out PE6 Data Sheet




Enclosure - 4 gang

£35.00

• Description
• Technical

• TimeGuard Outdoor Power Boxes for protection of plugs from dust and water.
  Also available with 2 gang socket.
  Suitable for all BS 13A plugs, transformer plugs and some timers.
  Tough, durable thermoplastic housing with retaining screws and supports for rigidity and IP seal.
  Not only ideal for outdoor and festive lighting but for ponds and fountains too!
• 4 Gang Box
   - IP Rating: IP65
   - Dimensions: 335*220*107mm
  1 x 20mm cable knock out  (mains in to socket strip)
  Cable seal outlets (to appliances)
  Full instructions and fitting guide is enclosed with the unit




SGMicro LED Module

£0.45

• Description
• Details at a glance
• Spacings Guide

• SGMicro 2-LED Modules

  Our SGMicro LED Module is amongst the tiniest of tiny LEDs. at only 25mm*5mm*2.5mm it's a perfect for those tight spaces without compromising on quality and still giving nice even light.
  For exceptional versatility, the SGMicro has 2 diodes per module and a wire length of 10mm between modules.

  Please download our specification PDF, in the tabs above, for more information.

  Available in 1 colour: Pure White (6500K)
  Rated: IP20


  Extra Info

  Need a power supply? See our 12v Power Supplies

  The 'SG' brand of LED modules are an efficient sign grade module. They offer the specification you need for most general signage requirements, with rock bottom prices.

  We Will Beat Any Like For Like Price!
  Seen it cheaper? Let us know



• Details at a Glance

  • Available in 1 colour: Pure White (6500K)
  • 25L*5W*2.5Dmm
  • 12V DC
  • 0.24W per module (at full power / White)
  • 25 lumens (at full power / White)
  • Pre-mounted adhesive tape to rear
  • 120° Beam Angle
  • 1 Year Warranty
  • 25,000hrs expected lifespan
  • IP20

• Spacings Info

  • 35mm - Full Stretch Centre to centre spacing
  • 30mm - Minimum return depth for even illumination


  • Row & LED Spacings Guide
    30mm Returns <  = 25mm spacings


  Click here to download our LED Modules Data Guide




2-way Y Distributor - Male to 2 Female

£2.00

• Description
• Technical

•  2-way Y Distributor with 1 Male Plug and 2 Female Sockets.

  The green mini connector system for 24v LED applications supplies the correct voltage.
  Various accessories as supply leads, extension leads, connecting leads, distributors and mini sockets can be provided for linking.


• Voltage rating: 24v
  Current rating: 10A
  AWG: 2no 0.75mm2
